Best K260A - Installation: Ductwork and Measurements; Ductwork Planning and Installation; Installation Dimensions

- 4 -
1. INSTALL DUCTWORK
Plan where and how the ductwork will
be located.
Install proper-sized ductwork,
transition(s), elbow(s), and roof or wall
cap for the type of blower you are using.
EXTERIOR BLOWER
EXTERIOR
BLOWER
HOOD
DECORATIVE
FLUE
or SOFFIT
HH0019A
12"
(305 mm)
24" TO 30" (609 to 762 mm)
ABOVE COOKING SURFACE
4-1/2" x 18-1/2" to
10"
(114 x 470 to
254 mm) ROUND
TRANSITION
(see page 3)
10" (254 mm)
ROUND DUCT
10" (254 mm)
ROUND DUCT
ROOF CAP
WALL CAP
HOOD
DECORATIVE
FLUE
or SOFFIT
4-1/2" x 18-1/2"
to 10"
(114 x 470 to
254 mm) ROUND
TRANSITION
(see page 3)
HH0018A
12"
(305 mm)
24" TO 30" (609 to 762 mm)
ABOVE COOKING SURFACE
7" (178 mm)
ROUND DUCT
ROOF CAP
7" (178 mm)
ROUND
ELBOW
24" TO 30" (609 to 762 mm)
ABOVE COOKING SURFACE
WALL CAP
HOOD
DECORATIVE
FLUE
or SOFFIT
12"
(305 mm)
HH0017A
2. MEASURE INSTALLATION
Standard
8 ft. (2.44 m)
ceiling
12"
(305 mm)
Standard
12" (305 mm)
soffit
- or -
FK260 Series
Soffit Chimney
13 "
(348 mm)
Top of wood
mounting strip
30"
(762 mm)
Standard 36"
(914 mm) H
cooktop
Hood
Cooktop
11
16
RMP Series
Backsplash
(optional)
HH0020A
Dimensions for the most common
installations are shown below.
Adjust your measurements for various
heights of ceilings, soffits, cabinets or
cooktops. For proper operation, the
hood must be a minimum of 24" and
a maximum of 30" above the cooktop.
18"
(457 mm)
Standard 18"
(457 mm) H
over-cooktop
cabinet
24"
(610 mm)
Cooktop
11
16
19 "
(500 mm)
Top of wood
mounting strip
Hood
RMP Series
Backsplash
(optional)
Standard
8 ft. (2.44 m)
ceiling
Standard 36"
(914 mm)
H cooktop
HH0021A
MODEL P6 SINGLE BLOWER
TYPICAL DUCTWORK
MODEL P12 DUAL BLOWER
TYPICAL DUCTWORK
MODEL EB6, EB9, EB12 OR EB15 EXT.
BLOWER TYPICAL DUCTWORK
