Best P3 - Installation Procedure; Vertical Discharge Installation; Horizontal Discharge Installation

MODELS P3 • P6
Page 3
INSTALLATION
1. Attach blower to mounting plate with (4) 10-24 Hex Nuts
(included).
2. Run power cable to installation location, remove knockout
from rough in plate wiring box.
VERTICAL DISCHARGE
HORIZONTAL DISCHARGE
3. Attach rough in plate to mounting studs at inside of hood
with (4) existing 10-32 Hex Nuts.
