BestCode Next Series 8 Technical Manual October 2022 Page 188 of 290

Solvent Filter (31-0021-01)

33-0001-02, Valve, 2 Way Ink

34-0003-02, Sensor, Ink Pressure

This image is

rotated 90°

20-0015-01,

Viscometer Assy, Complete
