51440, 51443 6
Rev. C 0301
Step Two - A
Note: If the vehicle is already equipped with brackets in the upper corners of the wind-
shield, skip to Step Three.
Position the Horizontal Rod Bracket in the upper corner of the windshield, flush with the
frame (see Figure 3a). Using the bracket as a template, mark the location of the (2) holes.
Center punch and drill the 5/32" holes. Secure the bracket to the windshield using (2) #10
Sheet Metal Screws. Repeat this procedure for the other bracket.
Figure 3a
Horizontal Rod Bracket
#10 S/M Screw
Windshield Frame
Area detailed at right
To Next Page
