1. POWER ON
ON/OFF switch with indication LED.
2.LEVEL
Control of the input level of the external signal: operates with continual values which vary from"
fully closed"(position" "-the signal is not fed to the amplifier sections) to "fully open"(position"
0dB")-the signal is sent to the amplifier sections at the same level as that with which it arrives at
the input).
3. BRIDGE
This LED will be light up when you choose "BRIDGE" mode on the back panel of this unit. There's
only output in CHA.
4.PROTEC
If this LED light up, this indicates that one of the various safeguarding the different sections of the
amplifier and the loudspeaker enclosure has tripped due to an operating fault.
5. CLIP
Display the status of the signal is when it has already been regulated by the input level controls.
6.SIGNAL
Signal "STATUS" indicators: these are LEDs able to indicate, for Channels A and B, a signal
presence in the inputs of the amplifier.
7. AIR VENTS
Amplifier cooling system air vents.
8. OUTPUTS
Power out: outs should be connected to the loudspeaker enclosures. All "T" SERIES amplifier's
A,B and BRIDGED outputs have a NL4 connector. Only loudspeaker(or loudspeaker enclosure
systems)within the amplifier's declared power and impedance load range should be connected to
the amplifier's outputs(see technical specification).
9.GROUND ON/FLOATING
Controls the separation of the electrical earth from that of the chassis.
10.INPUTS
HIGH PERFORMANCE POWER AMPLIFIERS
6
