VS3 - VS3 Octopus - VS3 NITROX Technical specifications
EUROPEAN EN 250 STANDARD.
All BEUCHAT regulators meet the European EN 250 - 2000 standard.
1 - VS3 SPECIFICATIONS
Yoke 230 bars - 3300 psi (Réf. : 316 700)
DIN 230 bars - 3300 psi (Réf. : 316 703)
The VS3 regulator are two stages regulators : the V3 pis-
ton first stage and the VS second stage.
VS3 Octopus SPECIFICATIONS
Yoke 230 bars - 3300 psi (Réf. : 316 713)
DIN 230 bars - 3300 psi (Réf. : 316 714)
The VS3 Octopus regulator is really a rescue regulator, of
which technical features are similar to those of VS3 unless
what follows : - Yellow hose “Super flow” 92,5 cm long
VS3 NITROX SPECIFICATIONS
EN 144-3 230 bars - 3300 psi (Réf. : 316 704)
The VS3 NITROX regulator are two stages regulators : the
V3 NITROX piston first stage and the VS NITROX second
stage.
A > V3 FIRST STAGE
The V3 first stage with a standard piston will lower the
high pressure air from your tank to relative adjustable of
9,6 bars / 145 psi. The VS second stage is connected with
a low pressure hose using one of the three port holes on
the first stage (Standard UNF 3/8" fitting).
B > VS second stage.
The second stage housing is injected in ABS Polycarbonate
material, and will provide maximum strength with mini-
mum weight. Both the diaphragm and exhaust valve are in
silicone to allow smooth inhalation and easy exhalation.
Note :
• The V3 first stage 3/8" LP ports can accommodate the
safe second stage octopus and the buoyancy compensa-
tor LP hose and / or drysuit inflator hose.
• On the 7/16" HP port, install a pressure gauge to check
air supply during the dive.
• A 3000/3300 psi DIN connection kit can be installed on
the V3 first stage by a BEUCHAT authorized dealer.
• A 3000/3300 psi DIN to yoke adapter is available under
Notice Detendeurs 07-2008 int.qxd 31/07/08 15:46 Page 36
