3. Device description
1. Cuff
2. Cuff line
3. Cuff connector
4. Display
5. Connection for cuff connector
6. Risk indicator
7. Connection for mains adapter
8. Function buttons -/+
9. START/STOPbutton
10. Memory button M
11. Setting button SET
Information on the display:
1. Time and date
2. Systolic pressure
3. Diastolic pressure
4. Calculated pulse value
5. Cardiac arrhythmia
symbol
pulse
symbol
6. Release air
7. Memory display:
average value ( ),
morning ( ),
evening ( ), memory
space number
8. Battery replacement symbol
9. Alarm function
10. Risk indicator
11. User memory
12. Cuff position control
13. Resting indicator display
91011
8
6
5
4
2
1
3
7
1
2
1
5678
2
3
4
9
11
10
13
12
25
