4.6.1 Spare parts list
No. Part Name Art. No. No. Part Name Art. No.
1 Armature with fan 230V 9230040 100 Retaining ring 9230014
1 Armature with fan 120V 9230063 102 Return line 9230013
17 Stator complete 230V 9230039 103 Pinion gear 9230012
17 Stator complete 120V 9230064 104 Nut 9230011
35 Carbon brush holder 9230037 105 Angle head 9230010
37 Ball bearing 9230036 106 Blocking bolt 9230009
38 Ball bearing 9230035 107 O-ring 9230008
39 Auto cut-out carbon brush 230V 9230034 108 Spring 9230007
39 Auto cut-out carbon brush 120V 9230065 109 Button 9230006
40 Stator screw fastening 9230032 110 Needle bush 9230005
41 Anti-kink guard 9230031 111 Screw 9230004
42 Special self-tapping screw 9230030 112 Seeger 9230003
43 Damping ring 9230029 113 Ball bearing 9230001
44 Support ring 9230028 114 Ball bearing 9230002
45 Annular magnet 9230027 115 Ring 9230067
46 Washer 9230026 117 Spindle 9230053
47 Countersunk head screw 9230025 118 Screw 9230052
48 Stator housing 9230038 119 Bearing cover 9230051
49 Fan cover 9230024 120 Washer 9230050
50 Eye protection 9230023 121 O-ring 9230049
52 Half-shell handle left 9230022 123 Bevel gear 9230048
53 Half-shell handle right 9230021 124 Grip handle 9230043
54 PT screw 9230020 130 Felt ring 9230046
55 PT screw 9230019 131 Adapter 9220010
56 Switch 9230018 132 Flange head premium 8233000
57 Cable clip 9230017 133 Adaptor pin 9220011
58 Power cable compl. 230V 9230062 134 Ball bearing screw M4 9233001
58 Power cable compl. 120V 9230061 140 Hex key wrench 5 mm 8120006
61 Electronic control 230V 9230015
61 Electronic control 120V 9230066
