K42 7

English

Setting the codes

Move the jumpers next to the digits that should

make up codes 1 and 2 respectively. NOTE! If only

one code (Code 1) is to be used, link terminal block

nos. 8 and 9 together. Do NOT leave any jumpers

off.

Example (see figure on page 4):

Code 1: 0123 Code 2: 4589

Timing the codes

The codes can be disabled for certain periods, e.g.

from a time clock. When terminal block nos. 7 and 9

are linked, code 1 is disabled. When terminal block

nos. 8 and 9 are linked, code 2 is disabled.

Remote opening/Exit Request

Between terminal block nos. 6 and 9, a time clock

(the lock is unlocked, e.g. daytime) or a N/O

pushbutton (exit request) can be connected.

Lock activating time

Set the lock activating time using the knob, variable

1-30 seconds. Normal time approx. 7 seconds.

Background Lighting

Set the jumper to ON to switch on the background

light for the keyboard.
