CA 4146 – Examples
25
english
Setup of the system with microphone stations and interpreter stations
1 MCS-D 200 control unit (push-pull socket)
2 MCS-D 3171 delegate microphone unit with push-pull sockets, language selector, voting buttons and display
2a MCS-D 3173 chairman microphone unit with PRIORITY and CLEAR buttons (configuration via MCS-D 200 control unit),
push-pull sockets, language selector, voting buttons and display
3 MCS-D 202 interpreter station, headset (or microphone and headphone)
4 CA 4146 power supply unit, 6 A
5 CA 4566 Digital / analogue interface (6 in / 6 out)
6 E.g. external transmitter for wireless transmisson
7 Cable
8 CA 4302 conference cable (2 m, push-pull)
9 CA 4213 adapter (T-adapter)
1
6
7
5
4
8
3
9
2a
2
