Beyerdynamic DT 250 - Microphone Specifications (DT 297 PV)

EN
DT 25x / DT 28x / DT 29x 11
DT 297 PV
Microphone
Transducer type ..........................condenser (back electret)
Frequency response .................................. 40 - 20,000 Hz
Polar pattern ...............................................cardioid
Output voltage at a diance of 5 cm ........................5.5 mV
Nominal impedance .........................................300 Ω
Load impedance ...........................................≥ 1000 Ω
Max. SPL ...................................................... 132 dB
S/N ratio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62 dB
Current consumption ...............................approx. 3.5 mA
Phantom powering ......................................... 12 - 48 V
Weight .................................................approx. 30 g
Frequency Response Curve
Frequency response curve ± 2.5 dB 0 dB = 5.5 mV
Wiring Diagram
Polar Pattern
Diance 1 m
