3 - MACHINE DESCRIPTION
3.1 Description of working cycle
Water coming from the tank at the back of the machine is sent to the boiler by a vibration pump
controlled by a switch on the front panel. Water is heated by an electrical resistance and temperature
is regulated and kept constant by contact thermostats located at the top of the boiler. Water passes
through a valve, crossing a boiler filter to the infusion area. Hot water or steam can be directly with-
drawn from the boiler through the faucet.
3.2 Description of controls (Fig. 01- Fig. 02)
1 Main Switch
2 Pump switch
3 General warning light temperature
4 Coffee delivery switch
5 Water/Steam faucet knob
6 Water/Steam distribution on
7 Group
8 Water level window (visual)
9 Water resevoir lid
10 Cup holder grid
11 Drain tray
12 Tank
13 Coffee delivery spout
14 2 cup filter
15 1 cup filter
16 Blind filter
17 Plug
18 Dose measurer
19 Press
20 Steam switch
21 Filter holder
3.3 Technical data (Fig. 03)
Power Supply V~/Hz 220 – 240V~ / 50-60Hz 110 – 120V~ / 50-60Hz
Resistance V 230 –240 110
Resistance W 1100 1100
Boiler lt 0,25
Tank lt 3
Width “A” mm 220
Depth “B” mm 250
Height “C” mm 350
Net Weight kg 10
Gross Weight kg 11
