8
Accessories
Power supply 230/115V AC
Swivel mount 1 inch and 2 inch flange disk
Heating insulator 1 inch
3-way ball cock 1 inch
Pressure screw joint 5bar size 1 inch
Optical adjusting device
Technical data
Spectral sensitivity
CFC 200 UV1 (formerly 8.0) 190 up to 550 nm
CFC 200 UV (formerly 8.30) 280 up to 420 nm
CFC 200 IR (formerly 8.40) 300 up to 1050 nm
CFC 200 IR3 (formerly 8.70) 1050 up to 2700 nm
Visual aperture 2.7 degrees
Input voltage 24 V DC
Current consumption approx. 200 mA
Construction according to SELV III
Ambient temperature -20°C...+70°C
Current output 0(4)...20 mA (Ra < 250 Ohm) flame intensity
Flame relay 1 change-over contact, potential free
VDE 0110, Class A
max. 48 V switching voltage
max. 1 A switching current (fused with 0.5 A)
max. 30 W switching power
switching point "flame on"5(8) mA
switching point "flame off"< 5(8) mA
Flame failure response time, 1 second, factory preset
switch-off time other switch off times on request
Sight tube connection 1" internal thread ISO 228
Purge air connection 1/2" internal thread ISO 228
Purge air quantity 10 m
3
/h at standard conditions
Electrical connection
Standard Harting connector HAN8 90 degrees
Flame proof housing 3m special cable
OE-Converter Harting connector HAN8 90 degrees
EX-OE-Converter M20-screw joint and terminal clamps inside
Dimension
Standard with flange 235 x 108 mm (Length x Diameter)
Explosion proof housing 223 x 120 mm (Length x Diameter)*
OE-Converter housing 120 x 122 x 80mm (Length x Width x Height)*
Ex-OE-Converter housing 232 x 232 x 166,5mm (Length x Width x Height)*
Triple Ex-OE-Converter 276 x 276 x 218mm (Length x Width x Height)*
*without plugs and mounting bracket
