BFT ELI BT A35 V - Left Door End-Stop Adjustment; Grub Screw Adjustment for Opening; Grub Screw Adjustment for Closing; Fastening Integrated End-Stops

0°
< 90°
>90°
M4
12
1
2
3
>90°
90°
<90°
120°
max
F
ASTENING OF INTEGRATED ENDSTOPS
PH1/ PH2
G
ADJUSTMENT OF INTEGRATED ENDSTOPS LEFT DOOR
Adjustment of grub screw for opening of left door
Adjustment of grub screw for closing of left door
