BFT ELI BT A35 V - Electrical Connections

ELI BT A
ELI AC A
M
OPEN CLOSE
CO M
M
ENCODER
H>300mm H>300mm
In order to comply with the regulatory
obligations and to preserve the integrity of the
installation, we recommend using slowdowns.
H
CO
NNECTIONS
Black or Brown Black or Brown
Black
Not supplied
Junction box
Junction box
Red Brown White Green
Bleu Yellow / Green
22 - ELI BT A35 V / AC A40 - ELI AC A35 V / AC A40
D814057 0AA96_01
