- 37 -
1
2
3
A
Spring coupling holes
Do not weigh the arm down by applying other accessories
TAB.1
Springs calibration (APPROXIMATE DATA)
REV.01
85
45
L
The values in the table are the same for the version with lights.
BTM-SKIRT
ADJ-FOOT
Special spring included in version XL. In these confi gurations, it is mandatory the installation of the bar reinforcement HYPHEN PS (see chap. 2.4 ref. )
ESDEFRENIT
MAXIMA ULTRA 36 •
BALANCING THE ARM
BOOM PS
BOOM PS
L 2000 2500 3000 3500 4000 4500 5000 5500 6000
BOOM PS
POSITION 1 1 1 1 1 2 2 3 3
A (mm) 130 125 110 90 125 115 100 120 105
BOOM PS
+ ADJ-FOOT
POSITION / 1 1 2 2 2 3 3
2
A (mm) / 110 90 125 115 100 125 110
95
BOOM PS
+ BTM-SKIRT
POSITION / 1 1 2 2 3 3
3
3
A (mm) / 110 85 120 100 120 105
125
115
BOOM PS
+ BTM-SKIRT
+ ADJ-FOOT
POSITION / 1 2 2 3 3 3
3
3
A (mm) / 95 120 105 125 110 95
120
105
