BFT Maxima Ultra 68 - 2 Installation; Overall Dimensions; Cable Note; Fixing the Structure

- 11 -
ENGLISH
RIGHT barrier
LEFT barrier
1) Single-phase line 2 x 1,5 + E
2) Transmitter photocell 2 x 0,5
3) Receiver photocell 4 x 0,5
4) Flashing light 2 x 0,5
5) Key selector 3 x 0,5
6) Receiver 4 x 0,5
6) Antenna RG58
7) Magnetic coil
Not supplied
590
1155
360
360
60170
953
1.5 OVERALL DIMENSIONS
2.1 CABLE NOTE
2.2 FIXING THE STRUCTURE
13mm
19mm
300
360
300
400
500
Ø80
400
600
6
5
3
1
7
2
4
590
170
360 60
1155
950
400
1. General information / 2. Installation
EN
