BFT Rigel 4 - Page 13

RIGEL 4 - 13
Fig. 1
Fig. 2
Fig. 3
Semaforo 1 esterno
Outside traffic light 1
Feu 1 extérieur
Ampel 1 Aussen
Semáforo 1 externo
Semaforo 2 interno
Inside traffic light 2
Feu 2 intérieur
Ampel 2 Innen
Semáforo 2 interno
Fuse 2A/T
5A/F (230V)
10A/F (110V)
0.2A/T (230V) 0.4A/T (110V)
F3
JP5
1
1
2
3
4
5
3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
2
1
2
3
4
5
1
2
K2
K1
JP2
JP1
DIP Function
1 Blinking
2 Red light in close position
DL3
DL1
DL4
DL2
JP4JP6
JP1
T.L.1
T.L.2
SSR4
JP1 JP6 JP4 JP5
JP5
F1 F2
1 2
M1
JP2
RICEV.
RIGEL4
TRAFFIC
LIGHT JP3
LINE
+ - + - + - + -
TW.PED
BFT / RIGEL4
TW TCA T.DELAY
1 2 3 4 5 6 7 8 910
ON
DIP function
1 FCH
2 IBL
3 TCA
4 HAMMER
5 DELAY OPN
6 2P/4P
7 PREALL
8 BLOCK
9 S.TW
10 U.P.
DL1
DL13
SWC2
DL12
SWO2
DL11
SWC1
DL10
SWO1
DL9
BAR
DL8
PHOT
DL7
STOP
DL6
CLOSE
DL5
OPEN
DL4
PED
DL3
START E
DL2
DL15
M2
DL16 DL14
START I
3 124 5 6 7 8 9 10 11 13 2214 15 16 17 18 19 20 21 23 3324 25 26 27 28 29 30 31 32
35 36 37 38 39 40
L N
M1 M2
40W max.
EBP
LINE
NEUTRE
R1
R1 R2
G1 G2
R2
G1
G2
230V
150W max.
24V
3W max.
ANT. CH2
NO
START I
COM
START E
PED
COM
OPEN
CLOSE
COM
STOP
PHOT
COM
SWO1
COM
SWC1
SWO2
COM
SWC2
NO NO NO NO NC
NC NC NC NC
NC
24Vac
Lock
12Vac
SCA
34
BAR
NC
