Installation Overview
3
Unit Installation
Overview
L N
1
2
3
4
5
MC MC
6
7
Install the indoor unit
(Page 8)
INSTALLATION ORDER
Install the outdoor unit
(Page 13)
Install the drainpipe
(Page 15)
Evacuate the refrigeration system
(Page 28)
Connect the wires
(Page 23)
Connect the refrigerant pipes
(Page 18)
Perform a test run
(Page 30)
