POMPE PER VUOTO LUBRIFICATE PBO – PBOM
OIL LUBRICATED VACUUM PUMPS PBO - PBOM
ALLEGATO “D”
SCHEMA DI COLLEGAMTO MOTORE
ENCLOSED“D”
MOTOR CONNECTION SCHEME
TRIFASE - 230/400V 50/60Hz
3 PHASE - 230/400V 50/60Hz
ATTENZIONE : in base al tipo di motore , il collegamento può variare da quanto sopra indicato. verificare all’interno del
coperchio morsettiera il tipo di collegamento esatto.
WARNING: depending on the motor's manufacturer, the above mentioned scheme could not be suitable. check in
the terminal box the wiring suggested before giving tension.
