BH LK500E - Page 17

17
STEP 5
Two people are required for this step. Run the control wire from the main frame through the
Control Tube Plastic Cover (K), and then into the side, up and out of the the Upper Control
Tube (E). Slide the Upper Control Tube (E), into the Control Tube Plastic Cover (K) (be
careful to not damage the wires). en, attached the Upper Control Tube (E) to the main frame
with Screws (10, 11, 12, 13). Push the Control Tube Plastic Cover (K) down until it is ush
with the main frame.
Note: While tightening the screws, be careful not to drop them into the main frame.

Control Wire
