PARTS LIST
To order replacement parts: provide your customer service representative with the product model
number and the part number located on the Parts List below, along with the quantity you require.
No. Description Qty No. Description Qty No. Description Qty
(A) FRAME AND ASSEMBLY FITTINGS 1set (E) REAR STABILIZER SET 1set I10 Carriage screw m8xp1.25X45 4
A01 Frame assembly 1 E01 Rear stabilizer set assembly 1 I11 Nut m8xp1.25 4
A02 Crank assembly 1 E02 Hex nut m8xp1.25 2 I12 Wave washer 4
A03 Idler assembly 1 E03 Adjustment foot pad 4 I13 Washer φ25xφ35x1.0T 2
A04 Belt wheel 1 E04 End cap φ75 (fc012) 2
A05 Hex screw 4 E05 Rear stabilizer protecting cover 1 (J) ROD SET 1set
A06 Nut 4 E06 End cap φ1-1/2”x2.0T 4 J01 Rod assembly R 1
A07 Belt 1 E07 Cks hex screw m10xp1.5X40 3 J02 Rod assembl L 1
A08 Spring A 1 E08 Spring washer m10 3 J03 Universal bearing 2
A09 Bearing 2 E09 Flat washer φ10xφ20x1.5T 3 J04 Nut m12xp1.75 4
A10 C-clip 1 E10 Screw m 4xp0.7X15 2 J05 Foam sticker 90x90x3.0T 2
A13
Flywheel
1 E11 Wheel board-punching 2 J06 Axle 2
A14 Flanch nut 2 E12 Screw m8xp1.25X15 4 J07 CKS hex screw m8xp1.25X15 4
A15 Hex nut 2 E13 Nut m8 4 J08 Plastic washer 2
A21 Lower control pc plate 1 E14 Foam sticker 4 J09 End cap 4
A22 Screw 2 E15 Washer φ4xφ10x1.0T 2 J10 Washer φ8.5Xφ19x2.0T 4
A23 Belt 4.8X330mm 7 J11 CKS hex screw m12xp1.75X40 2
A24 Belt 2.2X80mm 1 (F) PEDAL IRON TUBE AND FITTINGS 1 set J12 CKS hex screw bk m6xp1.0X10 2
A25 Belt 3.6X102mm 1 F01 Pedal iron tube assembly 2
A27 Sensor xed seat 1 F02 Bearing 16 (K) PLASTIC FITTINGS 1set
A28 Truss philips screw 1 F03 Wheel xing bushing 2 K01 Middle frame cover 1
A29 Power supply F04 Post φ18xφ23.7X7.2 8 K02 Pedal iron tube cover L 1
A30 Crank axle sleeve 1 F05 Wave washer φ17xφ24x0.3T 2 K03 Pedal iron tube cover R 1
A31 Small motor 1 F06 Retainer screw m8xp1.25X135 2 K04 Front handle tube cover L 1
A32 Cable 1 F07 Nut m8xp1.25 4 K05 Rear handle tube cover L 1
A33 Screw 4 F08 Wheel φ74x44 4 K06 Front handle tube cover R 1
A40 Wiring xed buttons 3 F09 Pedal xing plate assembly (front) 2 K07 Rear handle tube cover R 1
A41 Screw 3 F10 CKS hex screw m8xp1.25X85 2 K08 Rod cover L 2
A42 Screw 1 F11 Arc washer 4 K09 Rod cover R 2
A43 Washer 1 F12 Plastic iron core 2 K10 Pedal 2
A44 Washer 1 F13 Wheel cover L 2 K11 Control tube plastic 1
A45 Nut 1 F14 Wheel cover R 2 K12 Screw φ5x15 8
A46 Generator 1 F15 Screw m4xp0.7X15 4 K13 Screw m4xp0.7X15 6
A47 Screw 4 F16 Screw m8xp1.25X15 2 K14 Screw m5xp0.8X10 8
A48 Belt 1 F17 Washer φ8xφ25x2.0T 2 K15 Washer φ6xφ13x1.0T 8
A49 Battery 1 F18 Wave washer φ17xφ24x0.3T 2 K16 Screw m5xp0.8X10 1
A50 Foam sticker 2
(G) CONTROL TUBE SET 1set (L) COMPUTER CONSOLE AND WIRES 1set
(B) FRONT BASE TUBE SET 1set G01 Control tube welding 1 L01 Computer console 1
B01 Front base tube assembly 1 G02 CKS hex screw m10xp1.5X70 2 L02 Screw 2
B02 End cap 2 G03 CKS hex screw m8xp1.25X15 1 L04 Hand pulse wire 2
B03 Hex nut 2 G04 Nut 2 L06 Control wire 1
B04 Screw m8xp1.25X45 2 G05 Washer 1 L09 Speed sensor wire 1
B05 Nut m8xp1.25 2 G06 Guide thread 2 L10 Power supply wire 1
B06 Washer φ8xφ16x2.0T 2 L11 Battery power wire 1
B07 Bearing wheel 2 (H) HAND PULSE SET 1set L12 Small motor power wire 1
H01 Hand pulse plastic base 4
(C) CRUST SET 1set H02 Hand pulse sensor plate 4 (M) OTHERS 1set
C01 Lateral frame cover L 1 H03 Double sided tape 4 M01 Parts bag 1
C02 Lateral frame cover R 1 H04 Screw m3xp0.5X30 4 M02 Waterbottle Holder 1
C03 Plastic xing plate 2 H05 Hex nut m3xp0.5 4 M03 Waterbottle Holder Bracket 1
C04 Plastic xing plate-short 1 H06 End cap-φ1-1/4” 2 M04 Screw m6xp1.0X15 2
C05 Washer φ6xφ16x1.0T 2 M05 Washer ψ6xψ13x1.0T 2
C06 Screw m5xp0.8X10 10 (I) HANDLE SET 1set M08 Guide thread 4
C07 Screw m5xp0.8X12 2 I01 Handle tube assembly L 1 φ=Diameter
C08 Self tapping screw φ5x12 4 I02 Handle tube assembly R 1
I03 Bearing 4
(D) TURNPLATE CROSS AND FITTINGS 1set I04 Handle tube upper part assembly L 1
D01 Turnplate cross assembly 2 I05 Handle tube upper part assembly R 1
D02 Plastic turnplate 2 I06 HDR foam grip φ31x3.0Tx970 2
D03 Screw φ5x15 16 I07 End cap-φ1-1/4” 2
D04 Indented nut m14xp1.5X10t 2 I08 Screw m8xp1.25X15 2
D05 Turnplate protecting cover 2 I09 Flat washer φ8.5Xφ30x2.0T 2
