Big Dutchman 307pro - Introduction to 307 pro Climate Computer Manual; Mounting Guide for 307 pro Climate Computer

Circuit Diagrams and Cable Plans 7
307pro Climate computer
INTRODUCTION
This document contains a collection of examples of cable plans and circuit diagrams to be used for the
installation of a 307pro. The document may contain sections that are irrelevant to the house in question.
MOUNTING GUIDE
Figure 1: Outline of connections 307pro Combi-Tunnel
378
307pro
Aux. sensor
Pressure sensor
CO2
Alarm
Temperature sensor
Humidity sensor, Temp. sensor
Outside temp. sensor
Humidity sensor, Temperature sensor
Tunnel cooling sensor
Wall inlets
Front Rear
Rack and pinion
Front
Rear
Side mode
Tunnel mode
Step 1 Step 16
Step 1 Step 2 Step 16
Cooling pump
Cooling
Magnet valve
Local heat
Relay heat
Heating shunt
