BIGHORN SRCG16003 - Page 9

AA
Assembly Instructions
Attach wheels to legs with wheel axle and M12 nuts (CC).
Step 4
Attach firebox support to short legs with M6 x 12 bolts (AA).
Step 5
CC
M12 Nut
Hardware Used
2pcs
Hardware Used
Step 4
Step 5
8
AA
M6 x 12 Bolt 2pcs
Wheel axle
CC
M12 Nut
AA
Firebox support
