Biketronics BT1000 - AVC Programming Details; Handle-bar Control Functions

9
Color Chart for Hardwired Connection
Function Radio Harness Color Biketronics Module Wire Color
Switched 12 volts Red Red
Do not use as power source for additional accessories.
Constant 12 volts Yellow Yellow Ground Black Black Front Speaker-Right Grey (+) & Grey/Black (–) Grey (+) & Grey/Black (–) Front Speaker-Left White (+) & White/Black (–) White (+) & White/Black (–) Amp Remote Blue/White Stripe Not Used (Optional - Amplier) Rear Speaker-Right Purple (+) & Purple/Black (–) Not Used (Optional: Rear speakers) Rear Speaker-Left Green (+) & Green/Black (–) Not Used (Optional: Rear speakers) Antenna Remote Blue Not Used Phone Attenuate Light Blue Not Used Illumination Orange/White Stripe Not Used Kenwood/JVC Control Light Blue/Yellow BT1005 Only (Light Blue/Yellow)
BT1005: See page 16-17
SOLID INDICATES POSITIVE POLARITY (+)
STRIPES INDICATE NEGATIVE POLARITY (–)
