8
If radio wire harness or Biketronics module does not have the attached
white connector, these wires can be connected by soldering or
crimping. Use shrink tubing or high quality electrical tape to insulate
the joints.
WARNING!!
DISCONNECT the Biketronics module from Harley wire harness
before you start to solder or crimp wires. Failure to follow this
warning can result in an accidental short circuit that MAY damage
the Biketronics module electronics.
BIKETRONICS
MODULE/HARNESS WIRES
RADIO HARNESS
IF BOTH RADIO HARNESS AND BIKETRONICS MODULE HAVE
THE WHITE CONNECTOR USED TO CONNECT EACH OTHER, SKIP
THIS STEP.
You can purchase a Sony harness with this connector from Biketronics.
Radios purchased from Biketronics, Inc. come complete with white
connectors attached to harness and module.
Hardwire Radio Harness to Biketronics Module
Step 5
