1. Apply a small amount of grease to the lower portion of the post.
2. Open the cam lever on seat collar.
3. Slide the post into the desired height (seat posts have a minimum
insertion level marked on it, make sure this line is completely
hidden within the frame)
4. Close the cam lever (this is tight when it has resistance at mid-
point then close all the way).
Your Battery may ship separately due to logistical and regulatory requirements.
❖ To install the battery make sure the battery is correctly on the slide rail then slide it in & lock.
❖ To remove the battery, insert the key into the lock on the front left side of the battery, turn the key,
slide the battery forward, then lift out.
