Bilanciai D70E - Unpacking and Installation; Instrument Unpacking; Connection Guide; Powering On the Terminal

1. Unpacking and Installation
*
Not included
**
To connect the external battery to the 12V power supply, see the user manual.
Take instrument out of
package.
Connect:
A. 12V power supply **
B. Ethernet connector (RJ45)
C. RS232/485/422 serial
connection
D. weighing platform
E. D70E - Internal batteries
Press to turn on
instrument.
85-265 V
ac
50/60 Hz
A
B
C
D
ON/OFF
A B C D
E
*
*
D70E
