Part No. 500264 Form No. F071300A
Page 7 of 12
19
PARTS
LIST
ITEM BC2401HE BC2401H BC2401
NO. DESCRIPTION Part No QTY Part No QTY Part No QTY
1 Deck Assembly with labels 500239 1 500239 1 500239 1
2 Deck WA BC2401 500266 1 500266 1 500266 1
3 Deflector Front BC2400 500125 1 500125 1 500125 1
4 Base Assembly with labels 500240 1 500240 1 500240 1
5 Handle Brace Left 500196 1 500196 1 500196 1
6 Handle Brace Right 500200 1 500200 1 500200 1
7 Door Base Engine 500233 1 500233 1 500233 1
8 Transaxle 3 SPD BC2400 500100 1 500100 1 500100 1
9 Pulley 5.0" OD ‘A’ Sec. 830180 1 830180 1 830180 1
10 Belt Traction Drive 500119 1 500119 1 500119 1
11 Plate Pivot Idler / Shifter 500122 1 500122 1 500122 1
12 Shifter Pivot WA 500169 1 500169 1 500169 1
13 Pulley Idler 800260 1 800260 1 800260 1
14 Wheel & Tire 16" AG SP LH 500103 1 500103 1 500103 1
15 Wheel & Tire 16" AG SP RH 500104 1 500104 1 500104 1
16 Arm Idler WA 500170 1 500170 1 500170 1
17 Cable Clutch Blade BC2400 500259 1 500259 1 500259 1
18 Cable Clutch Drive BC2400 500146 1 500146 1 500146 1
19 Bar Shift T-axle 500121 1 500121 1 500121 1
20 Angle Support T-axle 500127 1 500127 1 500127 1
21 Rod Link Shifter 500144 1 500144 1 500144 1
22 Tube Shift With Grip 500171 1 500171 1 500171 1
23 Clutch Brake BC2401 500258 1 500258 1 500258 1
24 Grip 3/4 ID - Black 610102 1 610102 1 610102 1
25 Tube Pointer 500184 1 500184 1 500184 1
26 Plate Mount Idler WA 500228 1 500228 1 500228 1
27 Pulley Idler 4.5" OD X 3/8 500270 1 500270 1 500270 1
28 Shaft Traction Drive 500226 1 500226 1 500226 1
29 Belt Blade Drive 500237 1 500237 1 500237 1
30 Spacer Spindle BC2401 500232 1 500232 1 500232 1
31 Bar Guard WA BC2401 500235 1 500235 1 500235 1
32 Bushing Shifter 500130 1 500130 1 500130 1
33 Spacer Crank BC2401 500260 1 500260 1 500260 1
34 Spindle WA BC2400 500174 1 500174 1 500174 1
35 Bearing 7/8" ID Sealed Press 500101 2 500101 2 500101 2
36 Shaft Drive Blade 500107 1 500107 1 500107 1
37 Spacer Spindle Bearing 500115 1 500115 1 500115 1
38 Pulley 7" OD x 7/8" BORE 500253 1 500253 1 500253 1
39 Lever Control Blade 500312 1 500312 1 500312 1
40 Handle Upper BC2400 500243 1 500243 1 500243 1
41 Grip Handle 1 ID x 7.5 500267 2 500267 2 500267 2
42 Lever Control Clutch 500142 1 500142 1 500142 1
43 Bushing Lever Control 500152 4 500152 4 500152 4
44 Fitting Mount Cable 500187 2 500187 2 500187 2
45 Engine 11 HP Honda GXV340 Electric Start 500294 1 - - - -
Engine 11 HP Honda GXV340 - - 620100 1 500216 1
Engine 8.0 HP B & S - - - - 500216 1
46 Pulley Drive Traction BC2401 500238 1 500238 1 500238 1
47 Spacer Engine WA 2401 500262 1 500262 1 500262 1
48 Control Throttle BC2400 500308 1 500308 1 500213 1
49 Tube Cable Cover 500186 2 500186 2 500186 2
50 Blade 24" BC2400 500210 1 500210 1 500210 1
51 Handle Lower RH BC2400 500140 1 500140 1 500140 1
52 Handle Lower LH BC2400 500141 1 500141 1 500141 1
53 Adapter Blade WA 500191 1 500191 1 500191 1
54 Washer Friction Blade 500108 1 500108 1 500108 1
55 Guard Hand BC2401 500257 2 500257 2 500257 2
56 Screwcap 8x3/8 HWH Type B 100121 2 100121 2 100121 2
100 Washer Lock 5/16 Twist. Tooth 8177011 2 8177011 2 8177011 2
101 Bolt Carraige 1/4 - 20 x 3/4 8024021 4 8024021 4 8024021 4
102 Nut Lock 1/4 - 20 *8160001 14 *8160001 10 *8160001 10
103 Screw Cap 5/16 - 18 x 1 1/4 *8041029 18 *8041029 18 *8041029 18
104 Washer Lock 5/16 split *8177011 7 *8177011 7 *8177011 7
105 Plate Impeller Washer 850443 1 850443 1 850443 1
106 Screw Cap 7/16-20 X 3" 500269 1 500269 1 500269 1
107 SCREWCAP 5/16-18 X 1" *8041028 5 *8041028 4 *8041028 4
108 Screw Cap 5/16 - 18 x 2 3/4 *8041035 6 *8041035 6 *8041035 6
109 Bolt Carraige 5/16 - 18 x 3/4 8024039 2 8024039 2 8024039 2
110 Washer Flat 1/2" 900230 1 900230 1 900230 1
111 Pin Cotter 3/32 x 3/4" *8197016 1 *8197016 1 *8197016 1
To Next Page
