Part No 891058 Form No F042508A
17
KVSP/TKVSP Owner’s Manual
PARTS LIST KVSP/TKVSP
* Denotes
standard
hardware
item that
may be
purchased
locally.
ITEM
NO.
Description
KV600SP
PART
QTY
KV650SPH
PART
QTY
TKV650SPH
PART
QTY
1 MAIN FRAME HOUSING KV 891100-S 1 891100-S 1 891100-S 1
2 NOZZLE ASSEMBLY TKV 891110-S 1 891110-S 1 891110-S 1
3 AXLE FRONT WA KV 891103 1 891103 1 891103 1
4 PLATE TOP WA KVSP 891101-S 1 891101-S 1 891107-S 1
5 IMPELLER SERRATED 14.25 WA KVSP 891104-S 1 891104-S 1 891109-S 1
6 DOOR EXHAUST ASSY RAW 890148-01 1 890148-01 1 890148-01 1
7 WASHER 1/2" SAE Z/P 8172011 4 8172011 4 8172011 4
8 WHEEL ASSY 12" X 2.5" TREAD 900509 4 900509 2 900509 2
9 ENGINE 6.5 HP HONDA GSV190AN1L - - 840069 1 840069 1
ENGINE 6 BRIGGSAND STRATTON 890622 1 - - - -
10 LOWER HANDLE KV 891050 1 891050 1 891050 1
11 HANDLE UPPER KVSP 891054-S 1 891054-S 1 891054-S 1
12 QUICK DISCONNECT 890176 1 890176 1 890176 1
13 PIN CLEVIS 3/8" x 2.125" LONG 520120 4 520120 4 520120 4
14 RETAINER 360279 4 360279 4 360279 4
15 GRIP HANDLE 1"X 9.5" LG 430342 2 430342 2 430342 2
16 LABEL HOT ENGINE 400268 1 400268 1 400268 1
17 LABEL READ 890301 1 890301 1 890301 1
18 LABEL WARNING DANGER 400424 2 400424 2 400424 2
19 LABEL DANGER FLYING DEBRIS 810736 1 810736 1 810736 1
20 LABEL EAR EYE BREATHING 890254 1 890254 1 890254 1
21 BAG DEBRIS NO ZIPPER KV 891132 1 891132 1 891132 1
22 CABLE THROTTLE ASSY 42" W/CHOKE 891036 1 891027 1 891027 1
23 CABLE HGT ADJ TRIGGER KV 891001 1 891001 1 891001 1
24 CABLE CLUTCH DRIVE ASSY 40" KVSP 891032 1 891032 1 891032 1
25 LABEL CLUTCH VQ 900328 1 900328 1 900328 1
26 BRACKET TRANS MOUNT WA KV 891106 1 891106 1 891106 1
27 ARM IDLER DRIVE WA KV 891105 1 891105 1 891105 1
28 TRANS SINGLE SPEED W/DIFF 891020 1 891020 1 891020 1
29 SPROCKET 8 TOOTH #43 OR #65 891022 2 891022 2 891022 2
30 CHAIN #43 X 58 PITCHES 891023 2 891023 2 891023 2
31 GUARD DRIVE KV 891004-S 1 891004-S 1 891004-S 1
32 BEARING 1/2" PRESSED STEEL HOUSING 891025 2 891025 2 891025 2
33 BRACKET TRANS FIX KV 891012 1 891012 1 891012 1
34 PLATE CHAIN REINFORCE KV 891014 2 891014 2 891014 2
35 PULLEY IDLER 2" OD X 3/8" ID 840087 1 840087 1 840087 1
36 SPRING TENSION 800242 1 800242 1 800242 1
37 BAIL CLUTCH WA KVSP 891102 1 891102 1 891102 1
38 BRACKET IDLER BELT FINGER KV 891028 1 891028 1 891028 1
39 LABEL DANGER GUARD 900327 1 900327 1 900327 1
40 WHEEL ASSY SP 26T SPROCKET 890242 2 890242 2 890242 2
41 SPACER 1.50OD X .890ID X .5 THK - - 840083 1 840083 1
42 WASHER LOCK 3/8 TWISTED TOOTH 400502 1 400502 1 400502 1
43 SQ KEY 2.125 X .187 9201087 1 9201087 1 9201087 1
44 SCREW MACHINE #10-16 X 1 1/2" HWF ZP 891042 1 891042 1 891042 1
45 SCREWCAP 3/8-24 x 3 1/2 GR. 8 W/PATCH 440151 1 440151 1 440151 1
46 SCREWCAP 1/4 - 20 x 5/8 HWH 890359 28 890359 28 890359 26
47 BOLT IDLER 3/8-16 X 1 1/2 800888 1 800888 1 800888 1
48 WASHER 1/4" SAE ZP 8172007 17 8172007 17 8172007 20
49 WASHER 5/16 FLATWASHER Z/P 8171003 17 8171003 17 8171003 17
50 SCREW CAP 5/16-18 X 1.75 ZP 8041031 8 8041031 8 8041031 8
51 NUT LOCK 5/16-18 8160002 8 8160002 8 8160002 8
52 NYLON INSERT LOCKNUT, 3/8-16 UNC 8160003 2 8160003 2 8160003 2
53 SCREW CAP 1/4-20 X 3/4" 8041004 6 8041004 6 8041004 4
54 NYLON INSERT LOCKNUT, 1/4-20 UNC 8160001 15 8160001 15 8160001 18
55 SCREWCAP #10-14 X 3/4" HWH ZP 891043 3 891043 3 891043 3
56 1/2-13 CAP NUT NP W/PATCH 890530 4 890530 4 890530 4
57 SCREWCAP 1/4-20 x 1 3/4 HCS ZP 8041009 1 8041009 1 8041009 1
58 SCREWCAP 1/4-20x2.25x0.75-N 8041011 1 8041011 1 8041011 1
59 BELT 3L310 891026 1 891026 1 891026 1
60 SCREWCAP 1/4" - 20 X1 1/2" HCS ZP - - - - 8041008 1
61 NOZZLE TOP HALF KV 891002 1 891002 1 891002 1
62 NOZZLE BOTTOM HALF KV 891003 1 891003 1 891003 1
63 PLUG HOUSING KD LB 900146-01 1 900146-01 1 900146-01 1
64 SCREW PLASTIC 1/4-20 X 1 891039 8 891039 8 891039 8
65 WASHER 1.5 OD X .453 ID X .25 THK 440153 1 440153 1 440153 1
66 SCREW SELF TAP 10-24 X 1/2 8123086 1 8123086 1 8123086 1
67 SPROCKET 65A26 26 TOOTH
890238 1 890238 1 890238 1
68
WASHER LOCK 1/4" EXTERNAL TOOTH 8181007 5 8181007 5 8181007 5
69
SCREW SELF TAP 1/4 x 0.75 900505 5 900505 5 900505 5
70 SCREW TAPTITE 3/8 X 1 1/2 900564 3 900564 3 900564 3
71 SCREW CAP #10-24 X 5/8" - - - - 8059135 4
72 NYLON INSERT LOCKNUT 10-32 UNF ZINC - - - - 8164005 4
73 SCREW SOCKET HD 5/16-18 X 3/4 GR. 8 - - - - 890103 2
74 NUT KEPS 5/16-18 - - - - 890104 2
75 W ASHER SHIM 0.875 ID X 0.060 - - - - 891040 1
76 W ASHER SHIM 0.875 ID X 0.020 - - - - 891041 0-3
77 BLADE CHIPPER KD501 - - - - 890101 1
78 GUARD FLAPPER - - - - 890119 2
79 PLATE FLAPPER ENTRANCE - - - - 890127 2
80 BRACKET LOPPER LOOP - - - - 890167 1
81 TAMPER CHIPPER - - - - 890229 1
82 LABEL DANGER CHIPPER - - - - 890152 1
83 CLIP 1/2" 350146 4 350146 4 350146 4
84 W OODRUFF KEY 1/8 X 1/2 510180 2 510180 2 510180 2
85 HAIR PIN COTTER 1/4 900471 1 900471 1 900471 1
86 SPRING COMPRESSION KD HGT 900136 1 900136 1 900136 1
87 LABEL DECAL KV/TKV 891046 1 891046 1 891047 1
88 SCREW SM 1/4 X 3/4 DRILL PT 510208 4 510208 4 510208 4
89 W ASHER 1/4" SAE BLACK OXIDE 510193 4 510193 4 510193 4
91 BELT FINGER GUIDE 891063 2 891063 2 891063 2
92 CARRIAGE BOLT 1/4"-20 X 3/4" 8024021 2 8024021 2 8024021 2
93 SCREW CAP 1/4-20 X 1" HCS ZP 8041006 6 8041006 6 8041006 6
94 KV REINFORCEMENT NOZZLE BRACKET LFT 891062 1 891062 1 891062 1
95 KV REINFORCEMENT NOZZLE BRACKET RT 891064 1 891064 1 891064 1
96 WASHER SHIM 0.060 - - - - 891065 1
97 SPRING LEVER GZ 610429 1 610429 1 610429 1
