MV PUSH EU Owner’s Manual
Part No 840514 17 840514_B_HI
MV PUSH EU ENGINE PARTS LIST
ITEM
NO.
PART
NUMBER
DESCRIPTION
MV650HEU
QTY.
50 840282 ENGINE 6.5 HP HONDA GSV190 B4 1/1/19- EU 1
51 840100 IMPELLER 12.75 WA SP VAC 1
52 840111-S PLATE TOP PUSH VAC 1
53 840205 HOUSING PLASTIC VAC 1
54 440153 WASHER 1.5 OD X .453 ID X .25 THK 1
56 9201087 SQ KEY 2.125 X .187 1
57 840220 BRACKET COVER TOP PLATE VAC 1
58 890359 SCREW 1/4"-20 X 5/8" HWH 2
59 8172007 WASHER 1/4" SAE ZP 6
60 8172019 WASHER FENDER 1/4 ZP 6
61 8041004 SCREWCAP 1/4 - 20 x 0.75 HWH 6
62 790167 SCREWCAP 3/8-24X2 3/4" W/PATCH LOCK 1
63 900564 SCREWCAP 3/8"-16X2 1/2" TAPTITE 3
64 8177010 WASHER SPLIT LOCK 1/4" 6
65 8177012 WASHER LOCK 3/8" ST MED 1
67 840083 SPACER 1.50OD X .875ID X .5 THK 1
80 840215 TERMINAL 18-14 BLUE T-TAP 1
81 840213 SCREWCAP 1/4-20X5/8 GR. 5 6
