STEP 2 - CROWS NEST DECK ASSEMBLY
QTY
PART NUMBER DESCRIPTION
2
H100205 BOLT WH 5/16x2-1/4" BLK
2
H100198
WASHER LOCK EXT 8x19 BLK
2 H100379 T-NUT 5/16" BLK
TIP:
INSTALL T-NUTS IN WOOD FIRST
INSIDE VIEW
379 (x2)
T-NUT - 5/16"
198 (x2)
WASHER - 8x19
205 (x2)
BOLT - 2 1/4"
E04 (x2)
E04 (x2)
CROWS NEST DECK BRACE - W4L18292
1 7/16"x3 3/8"x10 7/8" (36x86x276)
E04
(x2)
