STEP 35 - FORT ASSEMBLY

855 (x2)

L BRACKET 51x32x82x3.175

659 (x8)

LAG SCREW - 1 1/2"

477 (x8)

WASHER - 5/16

478 (x8)

WASHER - 8x27

L BRACKET 51x32x82x3.175

(x2)

A4M00855

QTY

PART NUMBER

DESCRIPTION

8 H100659

LAG SCREW HEX 5/16x1 1/2 BLK

8 H100477 WASHER SPLIT 5/16 BLK

8 H100478

WASHER FLAT 8x27 BLK

NOTE:

USING BRACKET AS A GUIDE,

DRILL 3/16" (5 mm) X 1" DEEP

PILOT HOLES. 2 PLACES

EACH SIDE.
