Bilt Backyard Discovery WHISPERING POINT - Page 82

STEP 36 - FORT ASSEMBLY
QTY
PART NUMBER
DESCRIPTION
8 H100195
BOLT WH 5/16x2 3/4 BLK
8 H100198 WASHER LOCK EXT 8x19 BLK
4
H100379
T-NUT 5/16 BLK
TIP:
INSTALL T-NUTS IN WOOD FIRST
379 (x4)
T-NUT - 5/16"
195 (x8)
BOLT - 2-3/4
198 (x8)
WASHER - 8x19
F01 (x2)
F02 (x2)
CROWS NEST WALL SUPPORT - W4L18297
1 3/8"x2 3/8"x55" (36x60x1397)
F01
(x2)
CROWS NEST WALL SUPPORT - W4L18298
1 3/8"x2 3/8"x55" (36x60x1397)
F02
(x2)
82
