Bilt Backyard Discovery WHISPERING POINT - Page 84

STEP 38 - FORT ASSEMBLY
QTY
PART NUMBER DESCRIPTION
2 H100468 BOLT WH 5/16x1 BLK
2
H100471
LAG SCREW WH 5/16x1 1/2 BLK
2 H100379 T-NUT 5/16 BLK
TIP:
INSTALL T-NUTS IN WOOD FIRST
468 (x2)
BOLT - 1"
471 (x2)
LAG SCREW - 1 1/2"
379 (x2)
T-NUT - 5/16"
1047 (x2)
L BRACKET 2.5x38x55x55
L BRACKET 2.5x38x55x55
(x2)
A4M01047
ALIGN PILOT HOLES
84
