Name (number), function Adjustable value range Description
Default value
Unit system (P00c),
Unit system settings
Selectable values:
− Metric (EU), European unit system
− Imperial (US), US unit system
The units that can actually be used
(length, volume, weight) change
according to the unit system set
according to this parameter. When
setting or changing units, the unit
system must be selected first and
only then can the actual unit to
be used be set (according to the
previously narrowed list).
MAIN MENU / BASIC SETUP /
UNITS / ENGINEERING SYSTEM
Metric (EU)
Distance unit (P00b),
Length unit
Selectable values
Metric (EU):
− m
− cm
− mm
− custom unit
Imperial (US):
− inch
The unit of measurement for the
transmitter when the distance and
level are set.
If “custom unit” is selected, the
unit uses the unit of length as the
distance unit based on the value
specified in “User Unit.”
MAIN MENU / BASIC SETUP /
UNITS / ENGINEERING UNITS /
DISTANCE UNITS
m
Output unit,
volume (P02b)
Volume unit
Selectable values
Metric (EU):
− liter
− hl
− m3
− million liters
Imperial (US):
− gallon
− ft3
− barrel
− million gallons
The unit of the transmitted number
when set to volume measurement.
The device converts the measured
level into volume by calculation.
It is done by using a level-dependent
(non-linear) function.
It also gives the unit of measure for
the “Output” column in the VM table
(OC).
MAIN MENU / BASIC SETUP /
UNITS / ENGINEERING UNITS /
VOLUME UNITS
IT IS ONLY DISPLAYED IF THE PV IS
VOLUME!
liter
Output unit,
Weight (P02a)
Weight unit
Selectable values
Metric (EU):
− kg
− ton
− US ton
Imperial (US):
− lb
− US ton
− metric ton
The unit of the transmitter number
if the device is set for weight
measurement. The device converts
the measured level into weight.
It is done by using a level-dependent
(non-linear) function.
It also gives the unit of measure for
the “Output” column in the VM table
(OC).
MAIN MENU / BASIC SETUP /
UNITS / ENGINEERING UNITS /
MASS UNITS
IT IS ONLY DISPLAYED IF THE PV
IS WEIGHT!
kg
