Binks 183S-211-CE - Direct Drive Agitator; Direct Drive Agitator-Regulator Hook-Up

8
© ITW FINISHING SYSTEMS AND PRODUCTS
Note
Open side of sha seal (31) faces
downwards.
Retainer (32) required only for vacuum
operaon.
DIRECT DRIVE AGITATOR-REGULATOR HOOK-UP
DIRECT DRIVE AGITATOR
PG
PETROLEUM
JELLY/GREASE
PG
PG
Refer to SBBI-E-19-095 for
informaon about the
Agitator drive unit. Complete
drive ref is QMS-430-CE
FIG 3
For regulator parts
see page 13
