5/10/15-GALLON STAINLESS STEEL TANK ASSEMBLIES – SPECIFICATIONS & OPTIONS
SPECIFICATIONS
STAINLESS STEEL TANKS
Maximum Working Pressure 110 psi
Tank Shell 304 Stainless Steel
Tank Lid 304 Stainless Steel
Fluid Tube 3/8 in. SS Pipe, 316 Stainless Steel
Fluid Outlet (Elbow) S316 Stainless Steel
Fluid Valve, Outlet 316 Stainless Steel 3/8-18 NPS(M)
Agitator Paddle/Propeller Nylon, Glass Filled
Agitator Shaft 303 Stainless Steel
Agitator Shaft Seal Engineered PTFE, Stainless Steel
Air Manifold Steel, Zinc Plate
Plug (Air Manifold Coupling) 18-8 Stainless Steel
Bottom Outlet (Optional Kit) 304 Stainless Steel 3/4-14 NPS(M)
AIR CONTROL OPTIONS
TYPE APPLICATION
No Regulation (Air inlet pressure gauge
only)
Holding tanks, Transfer tanks, Used where precision fluid pressure control is not
required.
Standard Single Regulation
Provides standard uid pressure control only. For use where precision control of
both uid and air pressures is not required. Also Used where atomization air can
be taken from lter/regulator air lines.
Standard Double Regulation
Precision control for use with materials that are best applied at low, closely
controlled, uid and atomization air pressures. Used with portable air compressors
or with air lines when no other means of air pressure regulation is available.
Extra Sensitive Regulation Provides extremely accurate, low pressure, uid pressure control
Extra Sensitive Regulation with
Standard Gun Regulation
Provides extremely accurate, low pressure, uid pressure control plus precision
control of spray gun atomizing air.
AGITATION OPTIONS
TYPE APPLICATION
No Agitation
Materials that require minimal or no mixing and/or readily hold any solids in
suspension.
Gear-reduced Drive Agitation
Heavy-duty agitator for medium to high viscosity materials that require mixing
and/or solids suspension.
TANK CAPACITIES
Nominal
Capacity
Actual Capacity
5 US Gallons 9.8 US Gallons
10 US Gallons 11.8 US Gallons
15 US Gallons 19.8 US Gallons
