BIO-MED DEVICES IC-2A - Tidal Volume

32
TABLE II
TIDAL VOLUME
INSPIRATORY TIME (SEC.)
.40 .50 .75 1.00 1.50 2.00
20
130 170 250 330 500 670
30
200 250 375 500 750 1000
40
270 330 500 670 1000 1330
50
330 420 630 830 1250 1670
60
400 500 750 1000 1500 2000
70
470 580 875 1170 1750 2330
FLOW RATE (LPM)
75
500 630 940 1250 1880 2500
TIDAL VOLUME (ml.) = INSP. TIME X FLOW RATE (ml/sec.)
V
T
= T
I
X V
I
