2. Parts and Adjustments
6
1
13
E-Z Grip Handgrips
14
4
5
11
12
7
10
8
9
2
3
Figure 1: The Biodex Upper Body Cycle parts and adjustment mechanisms.
1. Display Panel
2. Seat Front-to-Back Release Handle
3. Seat Front-to-Back Scale
4. Actuator Adjust Locking Knob
5. Actuator Tilt Scale
6. Adjustable Arm Cranks
7. Battery Recharge Jack
8. RS-232 Jack
9. Rear Seat Stop (removable for wheelchair use)
10. Seat Rotation Handle (Clinical Pro only)
11. Seat Belt (Clinical Pro only)
12. Support Handles (Clinical Pro only)
13. Handgrips (E-Z Grip Handgrips on Clinical Pro only)
14. Arm Crank Locking Knobs
— 5 — PARTS AND ADJUSTMENTS
