4 MP System Hardware Guide
ACTIVITY
BUSY
MODE DESCRIPTION
A Bright
B Bright
Self-Test
Work
Error
ACTIVITY and BUSY be bright for the duration of the self-test and setup process.
This may take 3 – 10 seconds, depending on MP150 internal memory.
During data acquisition, ACTIVITY reflects command/data traffic (for acquisition
speeds of 1000 Hz or more, ACTIVITY will be permanently bright or blink at a high
frequency) and BUSY will be bright. It is normal for both lights to be on—this does
not indicate a problem unless you receive an Error Message on the computer screen.
ERROR: In rare cases, a serious problem may prevent a self-test and the lights may be
erratic: both on, both off, or any other static combination.
A Bright
B Blink
Error The MP150 enters the Error Mode if a fatal error occurs during the Self-test Mode. In
the Error Mode, ACTIVITY is bright and BUSY is blinking at a frequency of 5 Hz.
A Blink
B Bright
Error If the self-test fails or setup fails, the Error mode is initiated and ACTIVITY will blink
at about 5 Hz rate and BUSY will remain bright.
A Blink
B off
Idle-1
Idle-2
ACTIVITY blinks twice
with approximately 1.5-2 second interval and BUSY is OFF.
Double blink means:
- MP150 may be disconnected from LAN or,
- MP150 is connected to LAN but did not receive IP address from network’s
DHCP server and default 169.254.xxx.xxx address is self-assigned to MP150.
This is the standard state for MP150 connected to NIC through cross-over
network cable.
It means the MP150 is in working condition and ready for acquisition. AcqKnowledge
may communicate with the MP150 through a serial cable or through a network by
using 169.254.xxx.xxx address and/or cross-over cable.
ACTIVITY blinks once
with approximately 1.5-2 second interval and BUSY is OFF.
Single blink means:
- MP150 is connected to LAN and received IP address from network’s DHCP
server.
It means the MP150 is in working condition and ready for acquisition.
A off
B off
Self-Test
Wait
Error
ACTIVITY and BUSY will go dark for less than 1 second at the end of the self-test
before proceeding to the Idle mode.
Under some conditions, such as when you have a dialog box open, AcqKnowledge
cannot send commands to the MP150. When command flow from the workstation
stops, the MP150 acts as if you have an open dialog and enters the Wait Mode to wait
for a command from the workstation it is “locked” to—commands from any other
work station will be ignored. When it receives a command, the MP150 return to the
Work mode. After five minutes with no command communication, the MP150 will
revert to the Idle mode.
ERROR: In rare cases, a serious problem may prevent a self-test and the lights may be
erratic: both on, both off, or a static combination.
