46 MP System Hardware Guide
D. Transducer Calibration if not applying physical variable
Use this procedure if you can’t easily generate the required physical variable changes in order to calibrate the
transducer.
1. Calculate the de-normalized calibration factor, VY.
a) Note the factory calibration constant (generally listed as “Output” in the transducer
specifications), expressed in the form of voltage/physical variable (V/P),
b) Multiply V/P by the reference voltage (RV) of the DA100C (2 V factory preset).
c) Multiply the result [(V/P) * RV] by the Gain switch setting value on the DA100C.
2. Plug the transducer into the DA100C.
3. Press Cal 1 …this will generate VB in the Input Voltage box
4. Enter the ambient physical value in the Cal 1 Map/Scale window
5. Enter Cal 2 Input Voltage as V
Y
+V
B
6. Enter the ambient + delta physical value in the Cal 2 Map/Scale window
DA100C Specifications
Gain: 50, 200, 1000, 5000
Output Range: ±10V (analog)
Frequency Response
Low Pass Filter: 10Hz, 300Hz, 5000Hz
High Pass Filter: DC, 0.05Hz
Input Voltage (max): ±200mV (protected)
Noise Voltage: 0.11µV rms – (0.05-10Hz)
Temperature Drift: 0.3µV/°C
Z (Differential input): 2M
CMRR: 90dB min
CMIV—referenced to
Amplifier ground: ±10V
Mains ground: ±1500 VDC
Voltage Reference: -10 to +10V infinitely adjustable @ 20ma (max)
( preset to 2 volts excitation)
Signal Source: Variety of transducers
Input Voltage Range Gain
Vin (mV)
50 ±200
200 ±50
1000 ±10
5000 ±2
Weight: 350 grams
Dimensions: 4cm (wide) x 11cm (deep) x 19cm (high)
