33
Step 11. Secure the Velcro
®
tie downs over battery and securely
attach to the scooter frame.
Step 12. Reinstall the rear shroud and seat.
Seat and Tiller Adjustments
Ensure the scooter is on a level surface
Do not make adjustments while the scooter is moving
After making adjustments ensure all locks, levers and nuts
are tight and in the locked position
Seat Removal
The scooter’s parts can be heavy and difficult to maneuver, it is
always best to have assistance during the removal of the seat or
contact an authorized Thermor service center representative.
1. Ensure the tiller is in the most upright position.
2. Locate the seat rotation lever.
3. While gently pulling forward on the seat rotation lever, lift the
seat upwards.
Seat Rotation
The seat can be rotated left or right 90°.
1. Locate the seat rotation lever.
2. Push forward on the lever to disengage the seat.
