Displaying / Trouble shooting
4
Event / display Reason Solution
Memorise on transmitter:
Signal sounds for 10 seconds
Transmitter memory full.
The maximum number of
7 transmitters per output
has been exceeded
Delete memory
Memorise on transmitter:
No signal after transmitter
key press
No radio connection.
Frequencies of transmitter
and receiver must match
Set DIP switch correctly:
Frequency 1 (869.85 MHz)
or
Frequency 2 (868.95 MHz)
(Factory setting)
In operation:
Malfunctions (e.g. close
to a construction crane)
Highly disrupted radio
connection
Switch on automatic
frequency adaptation
On every actuation:
Signal sounds 2-4 times
Batteries soon depleted Change batteries
Technical data
5
System (RFGate 2.2.A)
Frequency bands 868.95 MHz & 869.85 Mhz
Range 25 m, under optimum conditions up to 75 m
Protection class (IEC 60529) IP 55
Pollution degree 2
Ball pressure test (IEC 695-10-2) PCB: 125°; housing: 75°
Software Class A
Working temperature -20°C to +55°C
Receiver (RFGate 2.2.R.A)
Transmitter memory
7 + 7
Output Relay
, 24 V, 0,5 A;
micro disconnection
1B
Supply voltage
12 / 24 VACDC
Power consumption
0.5 W @ 12 V, 1.2 W @ 24 V
Rated surge voltage (acc. to EN 60730-1) 300 V
Test signal input 12 / 24 VACDC
Dimensions 178 x 80 x 45 mm
Transmitter (RFGate 2.1.S, RFGate 2.1.S.NC) (RFGate 2.1.S.F)
Supply voltage 3 VDC (2 x Lithium CR2032)
Power consumption
When transmitting: 17 mA
In sleep mode: 16 µA
Dimensions 190 x 51 x 36 mm 190 x 51 x 22 mm
Declaration of conformity
6
Bircher Reglomat AG, Wiesengasse 20, CH-8222 Beringen, Switzerland, www.bircher-reglomat.com
7
Contact data
Manufacturer: Bircher Reglomat AG, Wiesengasse 20, CH-8222 Beringen, Employee responsible for docu.: Bircher Reglomat AG, Wiesengasse 20, CH-8222 Beringen
Product: Switching device with radio transmission system, Models: RFGate 2.1, RFGate 2.2, Serial numbers: WWYY000000 - WWYY999999, Notified Body: Suva certificate
authority, division: technics, EU-ID-number 1246, EC-type-examination certificates: E 6945, Following directives have been observed: Machinery directive 2006/42/EG,
R&TTE Directive 1999/5/EG, Following standards have been taken into account: EN ISO 13849-1, EN 12978,
Signee: CTO, Dr. M. Loschonsky / COO, D. Nef, CH-8222 Beringen
