Bison NB Series - HYDRAULIC CYLINDER ASSEMBLY PARTS

51
ASSEMBLY, HOSE AND CYLINDER LIST
REF.
41
42
43
44
45
46
47
48
PART
TA4110-6012-00
TA4120-1159-50
N/S
N/S
TA4430-1567-40
TA4430-1568-05
TA4110-4060-01
TA4110-4047-01
DESCRIPTION
QUICK MALE COUPLER 08MQBA-08FP(8010-04)
ELBOW 8MB-8MJ 90 WITH NUT
STRAP T50L9M4 15 1/2 "long
C. WAR. HIGH PRESSURE (19924-B)
MANG. 8M3K-8MP-8FJX-2.40
MANG. 8M3K-8MP-8FJX-3.05
CYLINDER 3 X 12 (B3001ABAAA07B)
CYLINDER 3 X 8 (BF-0385 Rev F)
NOT SELLED SEPARATEDLY
QTY.
6
6
12
3
4
2
N/S
NB80-052
Angle
47
Tilt
48
Offset
48
41
42
42
42
43
45
45
46
