Bison NB Series - Page 61

56
PARTS LIST & HYDRAULIC
CYLINDER ASSEMBLY KHCN102
REF.
1
2
3
4
5
6
7
8
9
10
11
A
B
C
D
E
F
PART
N/S
N/S
N/S
N/S
N/S
N/S
N/S
N/S
N/S
N/S
TA4110-4056-05
DESCRIPTION
CYLINDER ROD
CYLINDER LINER
SHAFT WITH NUT
COVER DOG WITH LUGS
COVER DOG
PISTON
CLEVIS
LOCK NUT 1-14
BOLT CYLINDER
COTTER 3/16 x 2
SEAL KIT FOR CYLINDER 3X8
POLIPACK TWO WAY
O-RING
O-RING
SUPPORT
CLEANER "U"
CLEANER "D"
N/S NOT SELLED SEPARATELY
QTY.
1
1
4
1
1
1
1
1
2
4
1
2
1
2
1
1
N/S
7
9
10
3
1
F
E
DB2CABD
4
10
9
8 6
9
10
7
1
6
8
A
C
B
D
E
F
3
2
3
B
D
10
9
4
3
3
5
5
11
11
3x8 CYLINDER
SEAL KIT
NB80-055
