1. BRACKET OF COLLISION BUMPER(LEFT) 15.FIXTY OF SAFETY PROTECTION GUARD
2. BRACKET OF COLLISTION BUMPER(FRONT) 16.SAFETY PROTECTION GUARD(RIGHT)
3. BOLT M8 (BG5781-86) 17.SAFETY PROTECTION GUARD(LEFT)
4. BRACKER OF COLLISION BUMPER(RIGHT) 18.FENDER FOR PADDY FIELD(LEFT)
5. NUT M8(GB41-86) 19.DOWEL
6. SPRING WASHER ￠8(GB93-87) 20.CONNECTING PLATE
7. WASHER ￠8(GB95-85) 21.BOLT M8×50(GB5781-86)
8. STAND (DIESEL) 22.CONNECTOR JOINTING ASSEMBLY
9. BRACKET(RIGHT) 23.DEEP FURROWING RESISTANCE STICK
10. NUT M6(GB41-86) 24.BOLT M8×25(GB5781-86)
11. SPRING WASHER ￠6(GB93-87) 25.BULLING SET (TROUGH COMP 16mm)
12. WASHER ￠6(GB95-85) 26.BRCRET OF FENDER COMP
13. BOLT M6×10(GB5781-86) 27.BRACKET (LEFT)
14. FENDER FOR PADDY FIELD (RIGHT)
ATTENTION: After maintenance the safety protection guard installment must fix it on the power tiller
wholly
