6. Technical data
Description OLC-D1 OLC-K1
Supply voltage 115 VAC; ±10%, 50/60 Hz, 3VA /
230 VAC; ±10%, 50/60 Hz, 3VA /
24 VAC/VDC, ±10%, 50/60 Hz, 3VA
115 VAC; ±10%, 50/60 Hz, 3VA /
230 VAC; ±10%, 50/60 Hz, 3VA
Max media temperature +120°C +100°C
Lock-out Failure Failure
Low oil level
Wires in cable 5 6
Compressor-start signal input No Yes; violet wire
Permitted ambient temperature Operation: -30°C – +60°C
Storage: -30°C – +80°C
Relative humidity Max. 95%RH non-condensing. Circuit board is
coated
Relay Switch voltage 240 VAC, min 24 VAC
Continuous current max 2.5A, min 20mA
Switching capacity 300 VA,
C300 (pilot type use according to UL508)
Fuse required Max 4A, fast-blow
Enclosure class Housing IP54; cable outlet pointing downwards
Mounting of the detection circuit Screw mounted, M24
Max. tightening torque: 10 Nm by hand only
Reset of lock-out state Interrupt supply power for min. 5 seconds
Cable length 2050 ±50 mm 950 ±50 mm
Weight 252 g 152 g
Dimensions 55.5 mm (w) x 87.0 mm (d) x 57.5 mm (h)
UL file number E348183
