9ST-600-2
L P
~ 1 c m
Ø 6 m m ( 1 / 4 ' ' )
3 0 °
A
B
C
Abb. 6 Saugleitungsführung bei
Parallelverbund
Fig. 6 Suction line runs for parallel com-
pounding
D
Fig. 6 Tracé de la conduite d'aspiration pour
des compresseurs en parallèle
