BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 19 -
ESC *
Function:
Specify bit image mode
Code:
ASCII
ESC
*
m
nL
nH
d1...dk
Hex
1B
2A
m
nL
nH
d1...dk
Decimal
27
42
m
nL
nH
d1...dk
Range:
m = 0, 1, 32, 33
0 ≤ nL ≤ 255
0 ≤ nH ≤ 3
0 ≤ d ≤ 255
k = nL + nH × 256 [in case of m = 0, 1]
k = (nL + nH × 256) × 3 [in case of m = 32, 33]
Default:
None
Description:
■ This command specifies the bit image for the mode m as to the number of dots specified by nL and nH.
• d specifies the bit image data with 1 for printed data and 0 for not printed.
• k denotes the number of horizontal dots.
DPI : Dots per Inch (25.4mm)
m
Mode
Number of dots in
vertical direction
Vertical dot
density (DPI)
Horizontal dot
density (DPI)
Number of bytes (k)
0
8-dot single-density
8
203/3
203/2
nL + nH x 256
1
8-dot double-density
8
203/3
203
nL + nH x 256
32
24-dot single-density
24
203
203/2
(nL + nH x 256) x 3
33
24-dot double-density
24
203
203
(nL + nH x 256) x 3
Remarks:
■ If the bit image data being entered is beyond the number of dots to be printed, the surplus will be discarded.
■ If the value of m is beyond the conditions, the subsequent data after m will be treated as normal data.
Differences:
None

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
